Lamp - when the remote is switched on, any press of a button will illuminate the screen (except for raising and lowering the head

and leg sections). In addition to this, the ‘Lamp’ button when pressed will illuminate the screen for approximately 10 seconds (can

be used when the remote is switched off).

Child Lock - for your safety the control is fitted with a Child Lock, to stop any unwanted use of the bed. Please note that you

can only activate the Child Lock when the remote is switched off (the position of the bed does not matter) . Remember, if

you have two remotes ensure both are locked if children are present.

To activate the Child Lock - press and hold the ‘Lamp’ button, then simultaneously press the ‘Leg Raise’ button. The Child Lock

is indicated by a ‘key’ displayed on the screen.

To deactivate the Child Lock - press and hold the ‘Power/Timer’ button for approx 5 seconds, or until the remote switches on.

The Child Lock is now deactivated and the ‘key’ image will be removed from the LCD screen.

Battery Back-Up - your Platinum 6 Bed features a Battery Back-Up system that allows you to reposition the bed in the event of

a mains power loss.

NOTE: The massage motors will not work without mains power. Upon resumption of mains power supply, the battery back up is

automatically recharged.

Once mains power is restored you can resume normal operation of the bed. Your favourite preset positions will remain programmed.

However, if necessary to re-set your ‘Favourite’ preset positions you will need to recalibrate your bed by re-setting the head and

leg lift motors on the bed. Please follow this procedure;

1.

Raise the back of the bed slightly.

2.

Next lower the Back to the flat/level position and then keep the ‘Back Lower’ button depressed for a further 6

seconds.

3.

Repeat this same sequence for the Leg section of the bed (do this one section at a time, do not try to do both at

once).

Failure to follow this procedure exactly as stated above, will result in your preset ‘Favourite Positions’ not functioning correctly.

If required, only use a Niagara Authorised Service Agent to change the back-up battery, located within the stainless-steel casing

of the Platinum 6 Bed control module.
